4 When you are finished, click OK.

Structural Column Type Properties - Steel

Properties will vary depending on the column families that are specified during the installation process. The
following type properties apply to the steel column families that load during a typical installation:
Name
Structural (Family parameters)
A
W
Dimensions (Family parameters)
bf
d
k
kr
tf
tw
Identity Data
Assembly Code
Keynote
Model
Manufacturer
Type Comments
URL
762 | Chapter 12 Working with Structural Components
NOTE Changes made to type parameters affect all structural columns of this type in the project. Click
Duplicate to create a new structural column type.
Description
Section area.
Nominal weight.
Flange width.
Actual depth of section.
k distance.
kr distance, read only.
Flange thickness.
Web thickness.
Uniformat assembly code selected from hierarchical list.
Add or edit the column keynote. Click the value box to open the Keynote dialog.
For more information see
Manufacturer internal number.
The shape manufacturer.
A field for entering general comments about the shape type. This information can
be included in a schedule.
Specifies a link to a web page that may contain type-specific information.
Keynotes on page 1058.
