Creating a Viewport Type

The following procedure assumes that you have created sheets in a project, and placed views on the sheets.
To create a viewport type
1 Open a sheet.
2 Select a viewport for a view on the sheet.
3 Click
4 In the Element Properties dialog, click Edit/New.
5 In the Type Properties dialog, click Duplicate.
6 In the Name dialog, enter a name for the new viewport type, and click OK.
7 Complete the parameters for the viewport type.
8 Click OK twice.
Revit Architecture applies the new viewport type to the selected viewport.

Applying a Viewport Type

After creating a viewport
assumes that you have created sheets in a project, placed views on the sheets, and created one or more
viewport types.
To apply a viewport type to a view on a sheet
1 Open a sheet.
2 Select a viewport.
3 In the Type Selector, select the viewport type to apply to the viewport.
Revit Architecture applies the viewport type to the selected viewport.
996 | Chapter 15 Preparing Construction Documents
The Type Selector displays a list of available viewport types.
.
See Viewport Type Properties
type, you can apply it to viewports on sheets in a project. The following procedure
on page 997.
