Modifying Ramp Properties

1 If you are in sketch mode, on the Design Bar, click Ramp Properties. If you are in a plan view,
2 In the Element Properties dialog, edit ramp instance parameters.
3 Click Edit/New to edit ramp type parameters.
4 Click OK.

Ramp Type Properties

Name
Construction
Thickness
Graphics
Text Size
Text Font
Materials and Finishes
Ramp Material
Dimensions
Maximum Incline Length
Identity Data
Keynote
Model
Manufacturer
678 | Chapter 11 Working with Architectural Components
select the ramp, and click
See Ramp Instance Properties
See Ramp Type Properties
NOTE Changes made to type properties affect all ramps of this type in the project. You can click
Duplicate to create a new ramp type.
Description
Sets the thickness of the ramp. This property is enabled only when the Shape
property is set to thick.
The size of the font for the ramp's up text and down text.
The font for the ramp's up text and down text.
Material applied to the surface of the ramp for rendering.
Specifies the maximum amount of consecutive rise in a ramp before a landing is
required.
Add or edit the ramp keynote. Click in the value box to open the Keynotes dialog.
See
Defines the ramp model.
Defines the ramp manufacturer.
.
on page 679.
on page 678.
Keynotes on page 1058.
