4 When you are finished, click OK.
Wall Reveal Type Properties
Name
Constraints
Default Setback
Construction
Profile
Wall Reveal Instance Properties
Name
Constraints
Offset from wall
Level
Offset from level
Dimensions
Length

Modifying Walls

After creating a wall, you can modify it by changing the wall type or resizing the wall.

Changing Wall Types

When you activate the Wall command to place walls, you can use the Type Selector to select different types
of walls.
Description
A length value whose default is 0.0. When set to positive or negative values, the
ends of the wall reveal curve pull back or push forward by the designated amount
when they are interrupted at an insert. This allows you to quickly set wall reveals
properly near window or door trims. This value is overwritten when you pull the
ends manually.
The profile family used to create the reveal.
Description
The distance from the wall face. This setting changes the depth of the reveal.
The reveal's level. This property only appears with horizontal reveals.
The reveal's offset from the level. This property only appears with horizontal reveals.
The length of the reveal.
