When you activate the Thin Lines command, it affects all views but does not affect printing or print preview.
To activate the command, click View menu

View Scale

The view scale is the proportional system used to represent objects in a drawing. You can assign a different
scale to each view in a project. You can also create custom view scales.
To assign view scale
1 In the Project Browser, right-click the view and click Properties.
2 In the Element Properties dialog, for View Scale, select a value.
To create a custom view scale
1 On the View Control Bar, click the view scale, and select Custom.
194 | Chapter 4 Project Views
Alternatively, you can select a scale from the View Control Bar.
Thin Lines, or click on the toolbar.
