TTR-LEV (TTR Level)
3. Execute display error. Look for a GPTD-PT, DTMR-PT, or CLSFY-PT that
has been busied out. A port that has been busied out has a value of 18 in
the error type field of the Hardware Error Log.
For each of the busied-out ports, use the following procedure:
If this does not clear the TTR Level alarm, proceed to Step 4.
4. Execute the display alarm command. Determine the address of the Tone
Detector circuit pack which contains the defective (alarmed) GPTD-PT or
DTMR-PT.
Execute the test board PCSS long rep 3 command where PCSS is the
address (that is, port network number, carrier designation, and slot
address) of the Tone Detector circuit pack or Call Classifier circuit pack
containing the defective (alarmed) GPTD-PT or DTMR-PT.
If this does not clear the TTR Level alarm, proceed to Step 5.
5. At this point, the only way to clear the alarm is to replace the Tone Detector
circuit pack or Call Classifier circuit pack containing the defective (alarmed)
GPTD-PT, DTMR-PT or CLSFY-PT.
Hardware Error Log Entries and Test to Clear
Values
Table 520. TTR Level Error Log Entries
Error Aux
Type Data
1 (a) 1
2 (b) 2
3 (c) 3
4 (d) 4
5 (e) 5
6 (f) 6
7 (g) 7
8 (h) 8
9 (i) 9
555-233-119
Determine why the port was busied out.
If the port can be placed back into service, test the port via the test
port PCSSpp command.
If all the tests pass, release the port via the release port PCSSpp
command. Then wait one minute for the TTR Level alarm to clear.
Associated Test Alarm Level
None
WARNING (See the
WARNING message
below)
None
WARNING
None
WARNING
MAJOR
MINOR
MINOR
On/Off
Board Test to Clear Value
OFF
OFF
OFF
OFF
OFF
OFF
