Avaya DEFINITY Server CSI Maintenance Manual page 1790

Maintenance Objects
Table 530. TEST #138 Loss of Signal Alarm Inquiry Test — Continued
Error Test
Code Result
1300 FAIL The CSU Module/T1 Sync Splitter or the E1 Sync Splitter is missing.
The CSU Module/T1 Sync Splitter is missing: The
field on the add ds1 form has been administered as
120A1 CSU Module or the 401A T1 Sync Splitter is not physically connected
to the UDS1 board on the back of the port carrier.
The E1 Sync Splitter is missing: The
add ds1 form has been administered as
Splitter is not physically connected to the UDS1 board on the back of the port
carrier.
1301 FAIL The 120A1 CSU Module or the 401A T1 Sync Splitter, or the 402A or 403A
E1 Synchronization Splitter is not expected.
The 120A1 CSU Module or the 401A T1 Sync Splitter is not expected: The
120A1 CSU Module/T1 Sync Splitter is physically connected to the UDS1
board on the back of the port carrier but the
the add ds1 form has not been administered as
The 402A or 403A E1 Synchronization Splitter is not expected: The 402A or
403A E1 Synchronization Splitter is physically connected to the UDS1 board
on the back of the port carrier but the
add ds1 form has not been administered as
1790
Issue 5 October 2002
Description/ Recommendation
1. If using the 120A1 CSU Module or the 401A T1 Sync Splitter, plug the
CSU Module/T1 Sync Splitter into the UDS1 circuit pack's connector on
the I/O connector panel on back of the carrier. Otherwise, change the
Near-End CSU Type
2. Run the test again.
1. If using the 402A or 403A E1 Synchronization Splitter, plug the E1SS into
the UDS1 circuit pack's connector on the I/O connector panel on back of
the carrier. Otherwise, change the
the change ds1 form to
2. Run the test again.
1. If the 120A1 CSU Module/T1 Sync Splitter is to be used, use the change
ds1 command to change the
integrated . Otherwise, physically remove the 120A1 CSU
Module/T1 Sync Splitter from the back of the port carrier.
2. Run the test again.
1. If the 402A or 403A E1 Synchronization Splitter is to be used, use the
change ds1 command to change the
. Otherwise, physically remove the 402A or 403A E1 Synchronization
y
Splitter from the back of the port carrier.
2. Run the test again.
Near-End CSU Type
integrated
field using the change ds1 form to
E1 Sync-Splitter?
y but the 402A or 403A E1 Sync
E1 Sync-Splitter?
.
n
Near-End CSU Type
integrated
Near-End CSU Type
E1 Sync-Splitter?
y .
E1 Sync-Splitter?
but the
other .
field on the
field using
field on
.
field to
field on the
field to
Continued on next page
