UDS1-BD (UDS1 Interface Circuit Pack)
If the circuit pack has an entry in the circuit plan and either of the other two
conditions are not met, a MINOR alarm is logged. To resolve the error
either:
1. Make sure that all conditions for administration are met and that a
2. Completely remove the UDS1-BD from the system using the
If all the administration conditions are met for this circuit pack and the red
LED is still on, follow the instructions for LED Alarms with Error Type 1 in
Chapter 7.
b. Error Type 18 — The UDS1 Interface circuit pack has been busied out by
a busyout board UUCSS command.
c. Error Type 23 — The UDS1-BD circuit pack is not completely
administered. To be fully administered, the UDS1 circuit pack must:
1. Have an entry in the circuit plan using the change circuit pack
2. Be administered using the add ds1 UUCSS command, and
3. Be physically inserted into the correct slot.
A DS1 (UDS1-BD and DS1-BD) differs from most circuit packs in that
inserting the circuit pack into the switch is not enough to make the board
usable. It must also be administered with the add ds1 command.
d. Error Type 125: No Aux Data — An incorrect circuit pack is inserted in the
slot where the USD1 circuit pack is logically administered. To resolve this
problem, either remove the incorrect circuit pack and insert the logically
administered circuit pack, OR use the change circuit-pack command to
re-administer this slot to match the circuit pack inserted.
Aux Data 3 — The 24/32-channel option jumper setting on the circuit pack
does not match the option set on the DS1 Circuit Pack administration
form. The circuit pack must be physically removed to see the setting of the
jumper.
e. Error Type 257 — is associated with the Common Port Circuit Pack
Maintenance Test. Refer to XXX-BD (Common Port Circuit Pack)
Maintenance documentation for details.
555-233-119
functioning UDS1 circuit pack is inserted in the correct slot, or
following steps:
a. Remove any administered DS1 trunks, access endpoints or
PRI endpoints associated with the circuit pack from their
trunk groups.
b. Execute the remove ds1 UUCSS and change circuit pack
UUCSS commands.
command,
