TSC-ADM (Administered Temporary Signaling
Connections)
System Technician-Demanded Tests: Descriptions
and Error Codes
Always investigate tests in the order presented in the following tables when
inspecting errors in the system. By clearing error codes associated with the TSC
Heartbeat Inquiry Test, for example, you may also clear errors generated
from other tests in the testing sequence.
Order of Investigation
TSC Heartbeat Inquiry Test (#604)
1. D = Destructive; ND = Nondestructive
TSC Heartbeat Inquiry Test(#604)
This test can be invoked by system technician personnel for any ADMTSC
administered in the switch. The following table indicates the possible error
conditions that might be encountered when the test is invoked. Most of the error
conditions do not log an error, but switched services may take some type of
recovery action in certain instances.
This test sends a USER INFORMATION TSC heartbeat message inquiry across
an Administered TSC to determine if the far-end can respond to a USER
INFORMATION TSC heartbeat message.
Table 519. TEST #604 TSC Heartbeat Inquiry Test
Error Test
Code Result
2100 ABORT
1005 ABORT
1113 ABORT
555-233-119
Description/ Recommendation
Could not allocate the necessary system resources to run this test.
1. Reissue the test tsc-administered command at 1-minute intervals a
maximum of 5 times.
The Administered TSC does not exist.
1. Display the administration for the Administered TSC.
2. If an Administered TSC is exists, reissue the test tsc-administered
command.
The D-channel is out-of-service.
1. Refer to the ISDN-LNK (ISDN-PRI Signaling Link Port) Maintenance
documentation.
Short Test Long Test
Sequence Sequence
Continued on next page
Issue 5 October 2002
1
D/ND
ND
1745
