Avaya DEFINITY Server CSI Maintenance Manual page 1756

Maintenance Objects
H600-513 cable pinout
Table 521 shows the pinout for the H600-513 cable assembly:
Table 521. H600-513 cable assembly pinout
TN2242
50-pin
connection pin
number
22
23
47
48
Administration
The TN2242 circuit pack requires board-level translation data. Before
administering any ports on the circuit pack, administer the following forms:
Circuit pack (change circuit pack)
DS1 (add ds1)
Trunk group (add trunk group n)
Table 522
required for this interface to operate successfully in Japan.
Table 522. TN2242 administration
Field
Trunk Group form, Page 1
Trunk Type (in/out)
Trunk Signaling Type
Answer Supervision Timeout
Receive Answer Supervision
Disconnect Supervision - In?
Disconnect Supervision - Out?
1756
Issue 5 October 2002
Color Lead Designation
W-BL Line in +
W-O Line out -
Bl-W Line in -
O-W Line out +
outlines the trunk group administration parameters that are
TDM
15-pin
connection pin
Color number
W-BL 4
W-O 9
Bl-W 11
O-W 2
Value
wink, delay, immed
(all permutations)
blank
0
y
y
y
Continued on next page
