Avaya DEFINITY Server CSI Maintenance Manual page 1730

Maintenance Objects
Table 512. Tone Generator Error Log Entries — Continued
Error Aux
Type Data
513(d,e) 17666 Tone Generator
Audit/ Update Test
(#41)
769 Any Transmission Test
(#40)
1025 Crosstalk Test
(#90)
1281 Any Tone Generator
Audit/ Update Test
(#41)
1. Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
Notes:
a. A failure in the tone generation facility on the indicated circuit pack has
been detected. Replace the circuit pack. See
Tone-Clock Circuit Pack''
b. This error type indicates that the circuit pack has been removed or has
been insane for more than 11 minutes. To clear the error, reinsert or
replace the circuit pack.
c. The tone generation facility is having problems verifying that tones have
been connected as requested.
d. The tone generation facility may or may not be able to generate tones.
e. Infrequent errors, at a rate which does not bring up an alarm, probably do
not affect service, unless there are customer complaints of no tones, or
incorrect tones which can not be explained in any other way. However, if an
alarm is raised because this error is being repeatedly logged, then the
circuit pack should be replaced. See
Pack''
1730
Issue 5 October 2002
Alarm
Associated Test Level
MINOR
MAJOR/
MINOR
MAJOR/
MINOR
MINOR
in the TONE-BD section.
in the TONE-BD section.
On/Off
Board Test to Clear Value
ON test tone-clock PC r 3
ON test tone-clock PC r 3
ON test tone-clock PC l r 2
ON test tone-clock PC r 3
Continued on next page
''How to Replace a
''How to Replace a Tone-Clock Circuit
