UDS1-BD (UDS1 Interface Circuit Pack)
Table 530. TEST #138 Loss of Signal Alarm Inquiry Test — Continued
Error Test
Code Result
1302 FAIL Attempting to use the 120A1 CSU Module with a UDS1 circuit pack that is
configured for 32-channel (2.048 Mbps) operation. The CSU Module only
works with a DS1 board configured for 24-channel (1.544 Mbps) operation in
the United States of America.
1303 FAIL The DS1 circuit pack Suffix is incorrect for CSU Module/T1 Sync Splitter or
E1 Sync Splitter administration.
The DS1 circuit pack Suffix is incorrect for CSU Module/T1 Sync Splitter
administration. The
been administered as
TN464F or later suffix UDS1 board.
The DS1 circuit pack Suffix is incorrect for E1 Sync Splitter administration.
The
administered as
UDS1 board.
1310 FAIL The DS1 Board Loopback (BLB) demand test (#1209) failed.
555-233-119
Description/ Recommendation
1. If the 120A1 CSU Module is to be used, physically remove the UDS1
circuit pack and reconfigure for 24-channel (1.544 Mbps) operation.
2. Reinsert the circuit pack and run the test again.
Near-End CSU Type
integrated
1. If the CSU Module/T1 Sync Splitter is to be used, and the
CSU Type field is set to
Sync Splitter administration, remove the circuit pack and replace it with a
TN464F or later suffix board. Otherwise use the change ds1 command
to change the
Near-End CSU Type
E1 Sync-Splitter?
y but the DS1 circuit pack is not a TN464F or later suffix
1. If the E1 Sync Splitter is to be used, and the
field is set to y to allow for E1SS administration, remove the circuit pack
and replace it with a TN464F or later suffix board. Otherwise use the
change ds1 command to change the
n .
1. Repeat the test using the test ds1-loop UUCSS
ds1/csu-loopback-tests command.
2. If the BLB test continues to fail, then replace the UDS1-BD circuit pack.
3. Run this test again.
field on the add ds1 form has
but the DS1 circuit pack is not a
integrated to allow for CSU Module/T1
field to
other
field on the add ds1 form has been
E1 Sync-Splitter?
E1 Sync-Splitter?
Continued on next page
