Avaya DEFINITY Server CSI Maintenance Manual page 1892

Maintenance Objects
Table 567. TEST #1104 VC DSPPT Local TDM Loopback Test
Error Test
Code Result
1000 ABORT
1001
1002 ABORT
1003 ABORT
1004 ABORT
2000 ABORT
2012 ABORT
2100 ABORT
2103 ABORT
0-3 FAIL
4-7 FAIL
PASS
1892
Issue 5 October 2002
Description/Recommendation
System resources required to run this test are not available, or the port is
busy with a valid call.
1. Retry the command at 1-minute intervals a maximum of 5 times.
The system could not allocate time slots for the test. The traffic load on the
system is very high, or time slots may be out-of-service due to TDM-BUS
errors. Refer to ''TDM-BUS (TDM Bus)''
1. If the system has no TDM-BUS errors and is not handling heavy traffic,
repeat the test at 1-minute intervals a maximum of 5 times.
The system could not allocate a Tone Detector for the test. The system is
oversized for the number of Tone Detectors present, or some Tone
Detectors are out-of-service.
1. Resolve any ''TTR-LEV (TTR Level)''
2. Resolve any ''TONE-PT (Tone Generator)''
3. If neither condition exists, retry the test at 1-minute intervals.
The port is seized by a user for a valid call. Use the status station command
for the station associated with this port and determine if the port is available
for testing.
1. Retry the command at 1-minute intervals a maximum of 5 times.
Response to the test was not received from the VC-BD circuit pack within the
allowable time period.
1. If this result occurs repeatedly, attempt to reset the port by using the
busyout port PCSSpp and reset port PCSSpp commands.
2. If this result occurs again, replace the circuit pack.
Internal system error
1. Retry the command at 1-minute intervals a maximum of 5 times.
Could not allocate the necessary resources to run this test.
1. Retry the command at 1-minute intervals a maximum of 5 times.
The system could not make the conference connection for the test.
1. Retry the command at 1-minute intervals a maximum of 5 times.
The TDM Looparound Test failed.
1. Replace circuit pack.
The Conference Circuit Test failed.
1. Replace circuit pack.
The VC DSP Port Local TDM Looparound Test passed.
to diagnose TDM Bus errors.
errors.
errors.
Continued on next page
