XXX-BD (Common Port Circuit Pack)

XXX-BD (Common Port Circuit Pack)
The Common Port Circuit Pack Maintenance is a set of common tests used by all
the circuit packs with the generic hardware that interfaces with the TDM bus.
Circuit packs included in this category are listed on the following pages.
MO Name (in
Alarm Log) Alarm Level
2
XXX-BD MAJOR
2
XXX-BD MINOR
2
XXX-BD WARNING
1. Where P is the port network number (1); C is the carrier designation (for example, A, B, or C); and
SS is the address of the slot in the carrier where the circuit pack is located (for example, 01, 02, etc.)
2. Refer to the appropriate circuit pack documentation to get the correct MO name displayed in this
field. It usually ends with BD.
Notes:
a. All circuit pack suffixes (B,C, D, etc.) are also supported by the XXX-BD
(Common Port Circuit Pack) Maintenance documentation.
b. The XXX-BD designation is also used in the SAT display in the case where
a reset board command is issued to a circuit pack type which is in conflict
to the actual circuit pack type administered for that slot or when a reset
board command is issued to an empty circuit pack slot.
When any of the Common Port Circuit Packs (except the TN754 Digital Line and
TN758 Pooled Modem circuit packs) are physically removed from the backplane,
no alarm is logged for approximately 11 minutes. In the case of the Digital Line
and Pooled Modem circuit packs, approximately 21 minutes elapse before an
alarm is logged. When a circuit pack that has been removed is alarmed, the alarm
type is minor and is classified as an on-board alarm. The time delay permits
maintenance activity to be performed without triggering an additional alarm. An
alarm is logged only against a Common Port Circuit Pack on which ports
have been administered. See the next Note.
NOTE:
In a heavily loaded system, the interval between the removal of a Common
Port Circuit Pack and the logging of the alarm may be several minutes
longer.
555-233-119
Initial Command to Run
test board PCSS
test board PCSS
test board PCSS
1
Full Name of MO
Common Port Circuit Pack
Maintenance
Common Port Circuit Pack
Maintenance
Common Port Circuit Pack
Maintenance
Issue 5 October 2002
1911
