Vc-Bd - Avaya DEFINITY Server CSI Maintenance Manual

Maintenance Objects
Table 563. TEST #1275 SCOTCH Synchronous Looparound Test — Continued
Error Test
Code Result Description/ Recommendation
FAIL VAL circuit pack detected test failure.
If the problem persists, reset the circuit pack (busyout board UUCSS, reset
board UUCSS, and release board UUCSS).
If the problem persists, replace the circuit pack.
PASS Port circuitry functioning properly.

VC-BD

MO Name (in
Alarm Log)
VC-BD MAJOR
VC-BD MINOR
VC-BD WARNING
1. Where P is the port network number (1 for PPN); C is the carrier designation (for example, A, B, or
C); and SS is the address of the slot in the carrier where the circuit pack is located (for example, 01,
02, etc.).
2. Refer to XXX-BD (Common Port Board) Maintenance documentation.
!
CAUTION:
If the TN788 Voice Conditioner Circuit Pack (VC-BD) is not Vintage 2 or
later, it must be replaced.
The TN788 Voice Conditioner Circuit Pack (VC-BD) is a service circuit pack that
provides conditioning for the audio signals from multimedia equipment based on
the CCITT H.221 standard. The TN788 transcodes, gain adjusts, and bridges the
audio bit streams demultiplexed by the TN787 (MMI) circuit pack and transmits
encoded, exclusive audio conference sums onto the TDM bus so that the MMI
can multiplex the audio, video, and data streams for the H.221 endpoints.
1884
Issue 5 October 2002
Alarm
Level Initial Command to Run
test board PCSS l r#
test board PCSS l r#
2
test board PCSS s r#
Continued on next page
1
Full Name of MO
Voice Conditioner Circuit Pack
Voice Conditioner Circuit Pack
Voice Conditioner Circuit Pack
