To display light sources in a view
1 Add lighting fixtures to the building model.
2 Open a view in which you can plan the placement of the lighting fixtures.
3 Turn on the visibility of light sources, as follows:
4 (Optional) On the View Control Bar, for Model Graphics Style, click Shading or Shading with

Aiming a Spotlight

In a building model, you can control the position of a spotlight to achieve the desired lighting effects. To
position a spotlight, use its angle parameters and the Rotate tool.
To aim a spotlight
1 Add spotlights to the building model, placing them in their approximate locations.
2 Set up views, as follows:
1130 | Chapter 17 Rendering
See Adding a Lighting Fixture to a Building Model
For example, to position spotlights that illuminate a wall, open a section view, elevation view,
or 3D view.
a Type vg, or click View
b On the Model Categories tab of the Visibility/Graphics dialog, expand Lighting Fixtures.
c Select Light Source.
NOTE To hide light sources in views, clear Light Source.
d Click OK.
Edges.
Shading allows you to see the difference between the beam angle and the field angle for spotlights.
(See Angles for Spotlights
See Adding a Lighting Fixture to a Building Model
a Leave open (or re-open) the view in which you added the lighting fixtures. (For this
procedure, this view is referred to as the placement view.) Zoom in on the fixtures, so you
can easily select them for rotating or repositioning. Turn on the display of light sources.
(See Displaying Light Sources in a View
b Select Window menu
c Open a second view in which you will be able to see the light cast on surfaces (such as an
elevation view, section view, or 3D view). (For this procedure, this view is referred to as the
lighting view.) On the View Control Bar, for Model Graphics Style, select Shading or Shading
with Edges. Turn on the display of light sources. (See
on page 1129.)
Visibility/Graphics.
on page 1132.)
on page 1129.)
Close Hidden Windows to close all other project views.
on page 1127.
on page 1127.
Displaying Light Sources in a View
