High-resolution timer (HRTIM)
26.5.13
HRTIM timer x interrupt status register (HRTIM_TIMxISR)
(x = A to F)
Address offset: Block A: 0x084
Address offset: Block B: 0x104
Address offset: Block C: 0x184
Address offset: Block D: 0x204
Address offset: Block E: 0x284
Address offset: Block F: 0x304
Reset value: 0x000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
DLYPR
Res.
RST
RSTx2
T
r
r
Bits 31:22 Reserved, must be kept at reset value.
Bit 21 O2CPY: Output 2 copy
This status bit is a raw copy of the output 2 state, before the output stage (chopper, polarity). It allows
to check the current output state before re-enabling the output after a delayed protection.
0: Output 2 is inactive
1: Output 2 is active
Bit 20 O1CPY: Output 1 copy
This status bit is a raw copy of the output 1 state, before the output stage (chopper, polarity). It allows
to check the current output state before re-enabling the output after a delayed protection.
0: Output 1 is inactive
1: Output 1 is active
Bit 19 O2STAT: Output 2 status
This status bit indicates the output 2 state when the delayed idle protection was triggered. This bit is
updated upon any new delayed protection entry. This bit is not updated in balanced idle.
0: Output 2 was inactive
1: Output 2 was active
Bit 18 O1STAT: Output 1 status
This status bit indicates the output 1 state when the delayed idle protection was triggered. This bit is
updated upon any new delayed protection entry. This bit is not updated in balanced idle.
0: Output 1 was inactive
1: Output 1 was active
Bit 17 IPPSTAT: Idle push-pull Status
This status bit indicates on which output the signal was applied, in push-pull mode balanced fault
mode or delayed idle mode, when the protection was triggered (whatever the output state, active or
inactive).
0: Protection occurred when the output 1 was active and output 2 forced inactive
1: Protection occurred when the output 2 was active and output 1 forced inactive
932/2083
28
27
26
25
Res.
Res.
Res.
12
11
10
9
SETx2
RSTx1
SETx1
r
r
r
r
24
23
22
Res.
Res.
Res.
O2CPY O1CPY
8
7
6
CPT2
CPT1
UPD
r
r
r
RM0440 Rev 1
21
20
19
18
O2
O1
STAT
STAT
r
r
r
r
5
4
3
2
Res.
REP
CMP4
CMP3
r
r
r
RM0440
17
16
IPP
CPP
STAT
STAT
r
r
1
0
CMP2
CMP1
r
r
