Advanced-control timers (TIM1/TIM8/TIM20)

The duty cycle and / or period changes are spread over 16 consecutive periods, as

described in the

Figure 303. PWM resolution vs frequency

PWM resolution

No Dithering

RM0440 Rev 1

PWM frequency
