General-purpose timers (TIM2/TIM3/TIM4/TIM5)
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:0 CCR3[19:0]: Capture/compare 3 value
28.5.22 TIMx capture/compare register 3 (TIMx_CCR3)(x = 2, 5)
Address offset: 0x03C
Reset value: 0x0000 0000
31 30 29
rw rw rw
15 14 13
rw rw rw
1286/2083
If channel CC3 is configured as output:
CCR3 is the value to be loaded in the actual capture/compare 3 register (preload value). It is
loaded permanently if the preload feature is not selected in the TIMx_CCMR3 register (bit
OC3PE). Else the preload value is copied in the active capture/compare 3 register when an
update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on tim_oc3 output.
Non-dithering mode (DITHEN = 0)
The register holds the compare value in CCR3[15:0]. The CCR3[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the integer part in CCR3[19:4]. The CCR3[3:0] bitfield contains the
dithered part.
If channel CC3 is configured as input:
CCR3 is the counter value transferred by the last input capture 3 event (tim_ic3). The
TIMx_CCR3 register is read-only and cannot be programmed.
Non-dithering mode (DITHEN = 0)
The CCR3[15:0] bits hold the capture value. The CCR3[19:16] bits are reserved.
Dithering mode (DITHEN = 1)
The register holds the capture in CCR3[19:0]. The CCR3[3:0] bits are reset.
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
24 23 22
CCR3[31:16]
rw rw rw
8 7 6
CCR3[15:0]
rw rw rw
RM0440 Rev 1
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
RM0440
17 16
rw rw
1 0
rw rw
