ST STM32G4 Series Reference Manual page 1143

RM0440
Bit 2 CC2IF: Capture/compare 2 interrupt flag
Bit 1 CC1IF: Capture/compare 1 interrupt flag
Bit 0 UIF: Update interrupt flag
27.6.6 TIMx event generation register (TIMx_EGR)(x = 1, 8, 20)
Address offset: 0x014
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:9 Reserved, must be kept at reset value.
Bit 8 B2G: Break 2 generation
This bit is set by software in order to generate an event, it is automatically cleared by
hardware.
0: No action
1: A break 2 event is generated. MOE bit is cleared and B2IF flag is set. Related interrupt
can occur if enabled.
Bit 7 BG: Break generation
This bit is set by software in order to generate an event, it is automatically cleared by
hardware.
0: No action
1: A break event is generated. MOE bit is cleared and BIF flag is set. Related interrupt or
DMA transfer can occur if enabled.
Refer to CC1IF description
If channel CC1 is configured as output: This flag is set by hardware when the counter
matches the compare value, with some exception in center-aligned mode (refer to the CMS
bits in the TIMx_CR1 register description). It is cleared by software.
0: No match.
1: The content of the counter TIMx_CNT matches the content of the TIMx_CCR1 register.
When the contents of TIMx_CCR1 are greater than the contents of TIMx_ARR, the CC1IF
bit goes high on the counter overflow (in upcounting and up/down-counting modes) or
underflow (in downcounting mode)
If channel CC1 is configured as input: This bit is set by hardware on a capture. It is
cleared by software or by reading the TIMx_CCR1 register.
0: No input capture occurred
1: The counter value has been captured in TIMx_CCR1 register (An edge has been
detected on tim_ic1 which matches the selected polarity)
This bit is set by hardware on an update event. It is cleared by software.
0: No update occurred.
1: Update interrupt pending. This bit is set by hardware when the registers are updated:
–At overflow or underflow regarding the repetition counter value (update if repetition counter
= 0) and if the UDIS=0 in the TIMx_CR1 register.
–When CNT is reinitialized by software using the UG bit in TIMx_EGR register, if URS=0
and UDIS=0 in the TIMx_CR1 register.
–When CNT is reinitialized by a trigger event (refer to
control register (TIMx_SMCR)(x = 1, 8,
register.
12 11 10 9
Res. Res. Res.
Advanced-control timers (TIM1/TIM8/TIM20)
20)), if URS=0 and UDIS=0 in the TIMx_CR1
8 7 6
B2G BG TG COMG
w w w
RM0440 Rev 1
Section 27.6.3: TIMx slave mode
5 4 3 2
CC4G CC3G CC2G
w w w w
1 0
CC1G UG
w w
1143/2083
