26.5.16 HRTIM timer x counter register (HRTIM_CNTxR) (x = A to F)
Address offset: Block A: 0x090
Address offset: Block B: 0x110
Address offset: Block C: 0x190
Address offset: Block D: 0x210
Address offset: Block E: 0x290
Address offset: Block F: 0x310
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 CNTx[15:0]: Timer x counter value
This register holds the timer x counter value. It can only be written when the timer is stopped (TxCEN
= 0 in HRTIM_TIMxCR).
Note: For HR clock prescaling ratio below 32 (CKPSC[2:0] < 5), the least significant bits of the counter
are not significant. They cannot be written and return 0 when read.
Note: The timer behavior is not guaranteed if the counter value is above the HRTIM_PERxR register
value.
26.5.17 HRTIM timer x period register (HRTIM_PERxR) (x = A to F)
Address offset: Block A: 0x094
Address offset: Block B: 0x114
Address offset: Block C: 0x194
Address offset: Block D: 0x214
Address offset: Block E: 0x294
Address offset: Block F: 0x314
Reset value: 0x0000 FFDF
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
24 23 22
Res. Res. Res.
8 7 6
CNTx[15:0]
rw rw rw
24 23 22
Res. Res. Res.
8 7 6
PERx[15:0]
rw rw rw
