ST STM32G4 Series Reference Manual page 1009

RM0440
26.5.68 HRTIM ADC trigger 3 register (HRTIM_ADC3R)
Address offset: 0x3C4
Reset value: 0x0000 0000
31 30 29
ADC3 ADC3 ADC3 ADC3
TEPER TEC4 TEC3 TFRST
rw rw rw
15 14 13
ADC3 ADC3 ADC3 ADC3
TFC3 TARST TAPER TAC4
rw rw rw
Bit 31 ADC3TEPER: ADC trigger 3 on timer E period
Refer to ADC3TAPER description.
Bit 30 ADC3TEC4: ADC trigger 3 on timer E compare 4
Refer to ADC3TFC2 description.
Bit 29 ADC3TEC3: ADC trigger 3 on timer E compare 3
Refer to ADC3TFC2 description.
Bit 28 ADC3TFRST: ADC trigger 3 on timer F reset and counter roll-over
Refer to ADC3TARST description.
Bit 27 ADC3TDPER: ADC trigger 3 on timer D period
Refer to ADC3TAPER description.
Bit 26 ADC3TDC4: ADC trigger 3 on timer D compare 4
Refer to ADC3TFC2 description.
Bit 25 ADC3TDC3: ADC trigger 3 on timer D compare 3
Refer to ADC3TFC2 description.
Bit 24 ADC3TFPER: ADC trigger 3 on timer F period
Refer to ADC3TAPER description.
Bit 23 ADC3TCPER: ADC trigger 3 on timer C period
Refer to ADC3TAPER description.
Bit 22 ADC3TCC4: ADC trigger 3 on timer C compare 4
Refer to ADC3TFC2 description.
Bit 21 ADC3TCC3: ADC trigger 3 on timer C compare 3
Refer to ADC3TFC2 description.
Bit 20 ADC3TFC4: ADC trigger 3 on timer F compare 4
Refer to ADC3TAC2 description.
Bit 19 ADC3TBRST: ADC trigger 3 on timer B reset and counter roll-over
Refer to ADC3TBRST description.
Bit 18 ADC3TBPER: ADC trigger 3 on timer B period
Refer to ADC3TAPER description.
Bit 17 ADC3TBC4: ADC trigger 3 on timer B compare 4
Refer to ADC3TFC2 description.
28 27 26 25
ADC3 ADC3 ADC3
TDPER TDC4 TDC3
rw rw rw rw
12 11 10 9
ADC3 ADC3 ADC3
TAC3 TFC2 EEV5
rw rw rw rw
24 23 22
ADC3 ADC3 ADC3 ADC3
TFPER TCPER TCC4 TCC3
rw rw rw
8 7 6
ADC3 ADC3 ADC3 ADC3
EEV4 EEV3 EEV2 EEV1
rw rw rw
RM0440 Rev 1
High-resolution timer (HRTIM)
21 20 19 18
ADC3 ADC3 ADC3
TFC4 TBRST TBPER
rw rw rw rw
5 4 3 2
ADC3 ADC3 ADC3
MPER MC4 MC3
rw rw rw rw
17 16
ADC3 ADC3
TBC4 TBC3
rw rw
1 0
ADC3 ADC3
MC2 MC1
rw rw
1009/2083
