ST STM32G4 Series Reference Manual page 1432

Low-power timer (LPTIM)
Bits 31:9 Reserved, must be kept at reset value.
Bits 8:7 Reserved, must be kept at reset value.
Bit 6 DOWNCF: Direction change to down clear flag
Writing 1 to this bit clear the DOWN flag in the LPTIM_ISR register.
Note: If the LPTIM does not support encoder mode feature, this bit is reserved. Please refer to
Section 31.3: LPTIM
Bit 5 UPCF: Direction change to UP clear flag
Writing 1 to this bit clear the UP flag in the LPTIM_ISR register.
Note: If the LPTIM does not support encoder mode feature, this bit is reserved. Please refer to
Section 31.3: LPTIM
Bit 4 ARROKCF: Autoreload register update OK clear flag
Writing 1 to this bit clears the ARROK flag in the LPTIM_ISR register
Bit 3 CMPOKCF: Compare register update OK clear flag
Writing 1 to this bit clears the CMPOK flag in the LPTIM_ISR register
Bit 2 EXTTRIGCF: External trigger valid edge clear flag
Writing 1 to this bit clears the EXTTRIG flag in the LPTIM_ISR register
Bit 1 ARRMCF: Autoreload match clear flag
Writing 1 to this bit clears the ARRM flag in the LPTIM_ISR register
Bit 0 CMPMCF: Compare match clear flag
Writing 1 to this bit clears the CMP flag in the LPTIM_ISR register
31.7.3 LPTIM interrupt enable register (LPTIM_IER)
Address offset: 0x008
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:9 Reserved, must be kept at reset value.
Bits 8:7 Reserved, must be kept at reset value.
Bit 6 DOWNIE: Direction change to down Interrupt Enable
0: DOWN interrupt disabled
1: DOWN interrupt enabled
Note: If the LPTIM does not support encoder mode feature, this bit is reserved. Please refer to
Section 31.3: LPTIM
1432/2083
implementation.
implementation.
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. Res.
implementation.
24 23 22
Res. Res. Res.
8 7 6
DOWNI
Res. Res. UPIE
E
rw
RM0440 Rev 1
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
ARRO CMPO EXT
KIE KIE TRIGIE
rw rw rw rw
RM0440
17 16
Res. Res.
1 0
ARRM CMPM
IE IE
rw rw
