RM0440
General-purpose timers (TIM2/TIM3/TIM4/TIM5)
Figure 360. Counter timing diagram, internal clock divided by 4
tim_psc_ck
CEN
tim_cnt_ck
Counter register
0035
0036
0000
0001
Counter overflow
Update event (UEV)
Update interrupt flag
(UIF)
MSv62301V1
Figure 361. Counter timing diagram, internal clock divided by N
tim_psc_ck
tim_cnt_ck
1F
Counter register
20
00
Counter overflow
Update event (UEV)
Update interrupt flag
(UIF)
MSv62302V1
RM0440 Rev 1
1193/2083
