High-resolution timer (HRTIM)
26.5.7 HRTIM master timer repetition register (HRTIM_MREP)
Address offset: 0x018
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 MREP[7:0]: Master timer repetition period value
This register holds the repetition period value for the master counter. It is either the preload register
or the active register if preload is disabled.
26.5.8 HRTIM master timer compare 1 register (HRTIM_MCMP1R)
Address offset: 0x01C
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 MCMP1[15:0]: Master timer compare 1 value
This register holds the master timer compare 1 value. It is either the preload register or the active
register if preload is disabled.
The compare value must be above or equal to 3 periods of the f
CKPSC[2:0] = 0, 0x30 if CKPSC[2:0] = 1, 0x18 if CKPSC[2:0] = 2,...
