Bits 15:0 Reserved, must be kept at reset value.
29.7.21 TIM15 DMA control register (TIM15_DCR)
Address offset: 0x3DC
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res.
Bits 31:13 Reserved, must be kept at reset value.
Bits 12:8 DBL[4:0]: DMA burst length
This 5-bit field defines the length of DMA transfers (the timer recognizes a burst transfer
when a read or a write access is done to the TIM15_DMAR address).
00000: 1 transfer,
00001: 2 transfers,
00010: 3 transfers,
...
10001: 18 transfers.
Bits 7:5 Reserved, must be kept at reset value.
Bits 4:0 DBA[4:0]: DMA base address
This 5-bit field defines the base-address for DMA transfers (when read/write access are
done through the TIM15_DMAR address). DBA is defined as an offset starting from the
address of the TIM15_CR1 register.
Example:
00000: TIM15_CR1,
00001: TIM15_CR2,
00010: TIM15_SMCR,
...
29.7.22 TIM15 DMA address for full transfer (TIM15_DMAR)
Address offset: 0x3E0
Reset value: 0x0000 0000
31 30 29
rw rw rw
15 14 13
rw rw rw
28 27 26 25
Res. Res. Res.
12 11 10 9
DBL[4:0]
rw rw rw rw
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
General-purpose timers (TIM15/TIM16/TIM17)
24 23 22
Res. Res. Res.
8 7 6
Res. Res.
rw
24 23 22
DMAB[31:16]
rw rw rw
8 7 6
DMAB[15:0]
rw rw rw
RM0440 Rev 1
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
Res. DBA[4:0]
rw rw rw
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
17 16
Res. Res.
1 0
rw rw
17 16
rw rw
1 0
rw rw
