Bit 5 UPIE: Direction change to UP Interrupt Enable
0: UP interrupt disabled
1: UP interrupt enabled
Note: If the LPTIM does not support encoder mode feature, this bit is reserved. Please refer to
Section 31.3: LPTIM
Bit 4 ARROKIE: Autoreload register update OK Interrupt Enable
0: ARROK interrupt disabled
1: ARROK interrupt enabled
Bit 3 CMPOKIE: Compare register update OK Interrupt Enable
0: CMPOK interrupt disabled
1: CMPOK interrupt enabled
Bit 2 EXTTRIGIE: External trigger valid edge Interrupt Enable
0: EXTTRIG interrupt disabled
1: EXTTRIG interrupt enabled
Bit 1 ARRMIE: Autoreload match Interrupt Enable
0: ARRM interrupt disabled
1: ARRM interrupt enabled
Bit 0 CMPMIE: Compare match Interrupt Enable
0: CMPM interrupt disabled
1: CMPM interrupt enabled
Caution: The LPTIM_IER register must only be modified when the LPTIM is disabled (ENABLE bit reset to '0')
31.7.4 LPTIM configuration register (LPTIM_CFGR)
Address offset: 0x00C
Reset value: 0x0000 0000
31 30 29 28
TRIG
Res. Res. SEL Res.
[3]
rw
15 14 13 12
TRIGSEL[2:0] Res.
rw rw rw
Bits 31:30 Reserved, must be kept at reset value.
Bits 28:25 Reserved, must be kept at reset value.
Bit 24 ENC: Encoder mode enable
The ENC bit controls the Encoder mode
0: Encoder mode disabled
1: Encoder mode enabled
Note: If the LPTIM does not support encoder mode feature, this bit is reserved. Please refer to
Section 31.3: LPTIM
implementation.
27 26 25 24
Res. Res. Res. ENC
rw
11 10 9 8
PRESC[2:0] Res.
rw rw rw
implementation.
23 22 21
COUNT
PRELOAD WAVPOL
MODE
rw rw rw
7 6 5
TRGFLT[1:0] Res.
rw rw
RM0440 Rev 1
Low-power timer (LPTIM)
20 19 18
WAVE TIMOUT TRIGEN[1:0]
rw rw rw
4 3 2
CKFLT[1:0] CKPOL[1:0]
rw rw rw
17 16
Res.
rw
1 0
CKSEL
rw rw
1433/2083
