Digital-to-analog converter (DAC)
Bits 15:14 HFSEL[1:0]: High frequency interface mode selection
00: High frequency interface mode disabled
01: High frequency interface mode compatible to AHB>80 MHz enabled
10: High frequency interface mode compatible to AHB>160 MHz enabled
11: Reserved
Bits 15:14 Reserved, must be kept at reset value.
Bits 13:10 Reserved, must be kept at reset value.
Bit 9 SINFORMAT1: Enable signed format for DAC channel1
This bit is set and cleared by software.
0: Input data is in unsigned format
1: Input data is in signed format (2's complement). The MSB bit represents the sign.
Bit 8 DMADOUBLE1: DAC channel1 DMA double data mode
This bit is set and cleared by software.
0: DMA Normal mode selected
1: DMA Double data mode selected
Bits 7:3 Reserved, must be kept at reset value.
Bits 2:0 MODE1[2:0]: DAC channel1 mode
These bits can be written only when the DAC is disabled and not in the calibration mode
(when bit EN1=0 and bit CEN1 =0 in the DAC_CR register). If EN1=1 or CEN1 =1 the write
operation is ignored.
They can be set and cleared by software to select the DAC channel1 mode:
– DAC channel1 in Normal mode
000: DAC channel1 is connected to external pin with Buffer enabled
001: DAC channel1 is connected to external pin and to on chip peripherals with Buffer
enabled
010: DAC channel1 is connected to external pin with Buffer disabled
011: DAC channel1 is connected to on chip peripherals with Buffer disabled
– DAC channel1 in sample & hold mode
100: DAC channel1 is connected to external pin with Buffer enabled
101: DAC channel1 is connected to external pin and to on chip peripherals with Buffer
enabled
110: DAC channel1 is connected to external pin and to on chip peripherals with Buffer
disabled
111: DAC channel1 is connected to on chip peripherals with Buffer disabled
Note: This register can be modified only when EN1=0.
21.7.17
DAC channel1 sample and hold sample time register
(DAC_SHSR1)
Address offset: 0x40
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
726/2083
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
rw
24
23
22
Res.
Res.
Res.
8
7
6
TSAMPLE1[9:0]
rw
rw
rw
RM0440 Rev 1
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
rw
rw
rw
rw
RM0440
17
16
Res.
Res.
1
0
rw
rw
