High-resolution timer (HRTIM)
TIMx update triggered by the master timer update
The sources listed in
the source event can be used to trigger a simultaneous update in any of TIMx timing units.
Operating condition: MSTU bit is set in HRTIM_TIMxCR register.
Source
Burst DMA end
Roll-over event following
a burst DMA end
Repetition event caused
by a counter roll-over
Repetition event caused
by a counter reset (from
HRTIM_SCIN or
software)
Software update
TIMx update triggered by the TIMy update
The sources listed in
given event can be used to trigger a simultaneous update in another or multiple TIMx timers.
Operating condition: TyU bit set in HRTIM_TIMxCR register (source = TIMy and
destination = TIMx).
Source
Burst DMA end
Update caused by the
update enable inputs
hrtim_upd_en[3:1]
Master update
Another TIMx update
(TIMz>TIMy>TIMx)
Repetition event caused
by a counter roll-over
Repetition event caused
by a counter reset
Counter roll-over
868/2083
Table 220 are generating a master timer update. The table indicates if

Table 220. Master timer update event propagation

Condition Propagation
BRSTDMA[1:0] = 01
BRSTDMA[1:0] = 10
MREPU = 1
MSWU = 1
Table 221 are generating a TIMy update. The table indicates if the

Table 221. TIMx update event propagation

Condition Propagation
UPDGAT[3:0] = 0001
UPDGAT[3:0] = 0011,
0100, 0101
MSTU = 1 in
HRTIM_TIMyCR
TzU=1 in
HRTIM_TIMyCR
TyU=1 in TIMxCR
TyREPU = 1
TyREPU = 1
TyRSTU = 1
RM0440 Rev 1
No Must be done in TIMxCR (UPDGAT[3:0] = 0001)
Yes -
Yes -
No -
All software update bits (TxSWU) are grouped in
No the HRTIM_CR2 register and can be used for a
simultaneous update
Must be done directly in HRTIM_TIMxCR
No
(UPDGAT[3:0] = 0001)
Must be done directly in HRTIM_TIMxCR
No
(UPDGAT[3:0] = 0011, 0100, 0101
Must be done with MSTU = 1 in HRTIM_TIMxCR
No
Must be done with TzU=1 in HRTIM_TIMxCR
No TzU=1 in HRTIM_TIMyCR
Yes -
- Refer to counter reset cases below
Yes -
