Figure 371. Counter timing diagram, internal clock divided by 4, TIMx_ARR=0x36

Counter register
Counter overflow
Update event (UEV)
Update interrupt flag
Note: Here, center_aligned mode 2 or 3 is updated with an UIF on overflow
1. Center-aligned mode 2 or 3 is used with an UIF on overflow.
Counter register
Counter underflow
Update event (UEV)
Update interrupt flag
tim_psc_ck
CEN
tim_cnt_ck
0034
(UIF)

Figure 372. Counter timing diagram, internal clock divided by N

tim_psc_ck
tim_cnt_ck
20
(UIF)
General-purpose timers (TIM2/TIM3/TIM4/TIM5)
0035
1F
RM0440 Rev 1
0036
01
00
0035
MSv62312V1
MSv62313V1
1201/2083
1297
