Figure 381. Capture/Compare Channel 1 Main Circuit; Figure 382. Output Stage Of Capture/Compare Channel (Channel 1, Idem Ch.2, 3 And 4) - ST STM32G4 Series Reference Manual

General-purpose timers (TIM2/TIM3/TIM4/TIM5)
The output stage generates an intermediate waveform which is then used for reference:
tim_ocxref (active high). The polarity acts at the end of the chain.
Read CCR1H
S
read_in_progress
Read CCR1L
R
Input
CC1S[1]
mode
CC1S[0]
IC1PS
CC1E
CC1G
TIMx_EGR

Figure 382. Output stage of capture/compare channel (channel 1, idem ch.2, 3 and 4)

tim_ocref_clr
tim_etrf
tim_ocref_clr_int
CNT > CCR1
CNT = CCR1
tim_oc2ref
1. Available on some instances only. If not available, tim_etrf is directly connected to tim_ocref_clr_int.
The capture/compare block is made of one preload register and one shadow register. Write
and read always access the preload register.
In capture mode, captures are actually done in the shadow register, which is copied into the
preload register.
1208/2083

Figure 381. Capture/compare channel 1 main circuit
