ST STM32G4 Series Reference Manual page 1357

RM0440
Bit 3 OC1PE: Output Compare 1 preload enable
Note: 1: These bits can not be modified as long as LOCK level 3 has been programmed
Bit 2 OC1FE: Output Compare 1 fast enable
Bits 1:0 CC1S[1:0]: Capture/Compare 1 selection
Note: CC1S bits are writable only when the channel is OFF (CC1E = '0' in TIM15_CCER).
29.7.9 TIM15 capture/compare enable register (TIM15_CCER)
Address offset: 0x20
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:8 Reserved, must be kept at reset value.
Bit 7 CC2NP: Capture/Compare 2 complementary output polarity
Refer to CC1NP description
Bit 6 Reserved, must be kept at reset value.
Bit 5 CC2P: Capture/Compare 2 output polarity
Refer to CC1P description
Bit 4 CC2E: Capture/Compare 2 output enable
Refer to CC1E description
0:Preload register on TIM15_CCR1 disabled. TIM15_CCR1 can be written at anytime, the
new value is taken in account immediately.
1:Preload register on TIM15_CCR1 enabled. Read/Write operations access the preload
register. TIM15_CCR1 preload value is loaded in the active register at each update event.
(LOCK bits in TIM15_BDTR register) and CC1S='00' (the channel is configured in
output).
2: The PWM mode can be used without validating the preload register only in one
pulse mode (OPM bit set in TIM15_CR1 register). Else the behavior is not guaranteed.
This bit is used to accelerate the effect of an event on the trigger in input on the CC output.
0: CC1 behaves normally depending on counter and CCR1 values even when the trigger is
ON. The minimum delay to activate CC1 output when an edge occurs on the trigger input
is 5 clock cycles.
1: An active edge on the trigger input acts like a compare match on CC1 output. Then,
tim_ocx is set to the compare level independently of the result of the comparison. Delay to
sample the trigger input and to activate CC1 output is reduced to 3 clock cycles. OCFE
acts only if the channel is configured in PWM1 or PWM2 mode.
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC1 channel is configured as output.
01: CC1 channel is configured as input, tim_ic1 is mapped on tim_ti1.
10: CC1 channel is configured as input, tim_ic1 is mapped on tim_ti2.
11: CC1 channel is configured as input, tim_ic1 is mapped on tim_trc. This mode is working
only if an internal trigger input is selected through TS bit (TIM15_SMCR register)
12 11 10 9
Res. Res. Res.
General-purpose timers (TIM15/TIM16/TIM17)
8 7 6
Res. CC2NP Res. CC2P
rw
RM0440 Rev 1
5 4 3 2
CC2E CC1NP CC1NE
rw rw rw rw
1 0
CC1P CC1E
rw rw
1357/2083
