ST STM32G4 Series Reference Manual page 1027

RM0440
26.5.80 HRTIM fault input register 3 (HRTIM_FLTINR3)
Address offset: 0x408
Reset value: 0x0000 0000
31 30 29
FLT4 FLT4
FLT4CNT[3:0]
RSTM CRES
rw rw rw
15 14 13
FLT2 FLT2
FLT2CNT[3:0]
RSTM CRES
rw rw rw
Bit 31 FLT4RSTM: Fault 4 reset mode
Refer to FLT5RSTM description.
Bit 30 FLT4CRES: Fault 4 counter reset
Refer to FLT5CRES description.
Bits 29:26 FLT4CNT[3:0]: Fault 4 counter
Refer to FLT5CNT description.
Bit 25 FLT4BLKS: Fault 4 blanking source
Refer to FLT5BLKS description.
Bit 24 FLT4BLKE: Fault 4 blanking enable
Refer to FLT5BLKE description.
Bit 23 FLT3RSTM: Fault 3 reset mode
Refer to FLT5RSTM description.
Bit 22 FLT3CRES: Fault 3 counter reset
Refer to FLT5CRES description.
Bits 21:18 FLT3CNT[3:0]: Fault 3 counter
Refer to FLT5CNT description.
Bit 17 FLT3BLKS: Fault 3 blanking source
Refer to FLT5BLKS description.
Bit 16 FLT3BLKE: Fault 3 blanking enable
Refer to FLT5BLKE description.
Bit 15 FLT2RSTM: Fault 2 reset mode
Refer to FLT5RSTM description.
Bit 14 FLT2CRES: Fault 2 counter reset
Refer to FLT5CRES description.
Bits 13:10 FLT2CNT[3:0]: Fault 2 counter
Refer to FLT5CNT description.
Bit 9 FLT2BLKS: Fault 2 blanking source
Refer to FLT5BLKS description.
Bit 8 FLT2BLKE: Fault 2 blanking enable
Refer to FLT5BLKE description.
28 27 26 25
FLT4
BLKS
rw rw rw rw
12 11 10 9
FLT2
BLKS
rw rw rw rw
24 23 22
FLT4 FLT3 FLT3
BLKE RSTM CRES
rw rw rw
8 7 6
FLT2 FLT1 FLT1
BLKE RSTM CRES
rw rw rw
RM0440 Rev 1
High-resolution timer (HRTIM)
21 20 19 18
FLT3CNT[3:0]
rw rw rw rw
5 4 3 2
FLT1CNT[3:0]
rw rw rw rw
17 16
FLT3 FLT3
BLKS BLKE
rw rw
1 0
FLT1 FLT1
BLKS BLKE
rw rw
