RM0440
However, if the memory space is limited, the X1 and Y buffer areas can be overlapped, such
that each output sample takes the place of the oldest input sample, which is no longer
required:
•
X2_BASE = 0;
• X1_BASE = N;
•
Y_BASE = N
In this case, Y_BUF_SIZE = X1_BUF_SIZE = N + d1, so that the buffers remain in sync.
Note: The FULL_WM field of X1 buffer configuration register must be programmed with a value
less than or equal to log
samples have been written, and no more samples will be requested. Similarly, the
EMPTY_WM field of the Y buffer configuration register must be less than or equal to
log (d2).
2
The filter coefficients must be pre-loaded into the X2 buffer, using the Load X2 Buffer
function. The X1 buffer can optionally be pre-loaded with any number of samples up to a
maximum of N. There is no point in pre-loading the Y buffer, since for the FIR filter there is
no feedback path.
After configuring and initializing the buffers, the FMAC_CR register should be programmed
according to the method used for writing and reading data to and from the FMAC memory.
Three methods are supported:
•
Polling: No DMA request or Interrupt request is generated. Software must check that
the X1_FULL flag is low before writing to WDATA, or that the Y_EMPTY flag is low
before reading from RDATA.
•
Interrupt: The interrupt request is asserted while the X1_FULL flag is low, for writes, or
when the Y_EMPTY flag is low, for reads.
• DMA: DMA requests are asserted on the DMA write channel while the X1_FULL flag is
low, and on the read channel while the Y_EMPTY flag is low.
Different methods can be used for read and for write. However it is not recommended to use
both interrupts and DMA requests for the same operation
listed in Table
WIEN
0
0
1
1
0
0
0
a. If both interrupts and DMA requests are enabled then only DMA should perform the transfer.
(d1), otherwise the buffer will be flagged full before N input
2
106.

Table 106. Valid combinations for read and write methods

RIEN DMAWEN
0
1
0
1
0
0
0
RM0440 Rev 1
Filter Math Accelerator (FMAC)
(a)
DMAREN
0 0
0 0
0 0
0 0
0 1
1 0
1 1
. The valid combinations are
Write
Polling Polling
Polling Interrupt
Interrupt Polling
Interrupt Interrupt
Polling DMA
DMA Polling
DMA DMA
Read
459/2083
