Flexible memory controller (FMC)
Bits 3:2 MTYP[1:0]: Memory type.
Defines the type of external memory attached to the corresponding memory bank:
00: SRAM/FRAM (default after reset for Bank 2...4)
01: PSRAM (CRAM) / FRAM
10: NOR Flash/OneNAND Flash (default after reset for Bank 1)
11: reserved
Bit 1 MUXEN: Address/data multiplexing enable bit.
When this bit is set, the address and data values are multiplexed on the data bus, valid only with
NOR and PSRAM memories:
0: Address/Data non multiplexed
1: Address/Data multiplexed on databus (default after reset)
Bit 0 MBKEN: Memory bank enable bit.
Enables the memory bank. After reset Bank1 is enabled, all others are disabled. Accessing a
disabled bank causes an ERROR on AHB bus.
0: Corresponding memory bank is disabled
1: Corresponding memory bank is enabled
SRAM/NOR-Flash chip-select timing register for bank x (FMC_BTRx)
Address offset: 0x04 + 8 * (x – 1), (x = 1 to 4)
Reset value: 0x0FFF FFFF
This register contains the control information of each memory bank, used for SRAMs,
PSRAM and NOR Flash memories.If the EXTMOD bit is set in the FMC_BCRx register, then
this register is partitioned for write and read access, that is, 2 registers are available: one to
configure read accesses (this register) and one to configure write accesses (FMC_BWTRx
registers).
31 30 29
DATAHLD[1:0] ACCMOD[1:0]
rw rw rw
15 14 13
rw rw rw
Bits 31:30 DATAHLD[1:0]: Data hold phase duration
These bits are written by software to define the duration of the data hold phase in HCLK
cycles (refer to
For read accesses
00: DATAHLD phase duration = 0 × HCLK clock cycle (default)
01: DATAHLD phase duration = 1 × HCLK clock cycle
10: DATAHLD phase duration = 2 × HCLK clock cycle
11: DATAHLD phase duration = 3 × HCLK clock cycle
For write accesses
00: DATAHLD phase duration = 1 × HCLK clock cycle (default)
01: DATAHLD phase duration = 2 × HCLK clock cycle
10: DATAHLD phase duration = 3 × HCLK clock cycle
11: DATAHLD phase duration = 4 × HCLK clock cycle
512/2083
28 27 26 25
DATLAT[3:0]
rw rw rw rw
12 11 10 9
DATAST[7:0]
rw rw rw rw
Figure 51
24 23 22
CLKDIV[3:0]
rw rw rw
8 7 6
ADDHLD[3:0]
rw rw rw
to Figure 63), used in asynchronous accesses:
