26.5.69 HRTIM ADC trigger 4 register (HRTIM_ADC4R)
Address offset: 0x3C8
Reset value: 0x0000 0000
31 30 29
ADC4 ADC4 ADC4 ADC4
TERST TEC4 TEC3 TEC2
rw rw rw
15 14 13
ADC4 ADC4 ADC4 ADC4
TFC3 TBC2 TAPER TAC4
rw rw rw
Bit 31 ADC4TERST: ADC trigger 4 on timer E reset and counter roll-over
Refer to ADC4TCRST description.
Bit 30 ADC4TEC4: ADC trigger 4 on timer E compare 4
Refer to ADC4TAC2 description.
Bit 29 ADC4TEC3: ADC trigger 4 on timer E compare 3
Refer to ADC4TAC2 description.
Bit 28 ADC4TEC2: ADC trigger 4 on timer E compare 2
Refer to ADC4TAC2 description.
Bit 27 ADC4TDRST: ADC trigger 4 on timer D reset and counter roll-over
Refer to ADC4TCRST description.
Bit 26 ADC4TDPER: ADC trigger 4 on timer D period
Refer to ADC4TAPER description.
Bit 25 ADC4TDC4: ADC trigger 4 on timer D compare 4
Refer to ADC4TAC2 description.
Bit 24 ADC4TFPER: ADC trigger 4 on timer F period
Refer to ADC4TAPER description.
Bit 23 ADC4TDC2: ADC trigger 2 on timer D compare 2
Refer to ADC4TAC2 description.
Bit 22 ADC4TCRST: ADC trigger 4 on timer C reset and counter roll-over
This bit enables the generation of an ADC trigger upon timer C reset and roll-over event, on ADC
trigger 1 output.
Bit 21 ADC4TCPER: ADC trigger 4 on timer C period
Refer to ADC4TAPER description.
Bit 20 ADC4TCC4: ADC trigger 4 on timer C compare 4
Refer to ADC4TAC2 description.
Bit 19 ADC4TFC4: ADC trigger 4 on timer F compare 4
Refer to ADC4TAC2 description.
Bit 18 ADC4TCC2: ADC trigger 4 on timer C compare 2
Refer to ADC4TAC2 description.
Bit 17 ADC4TBPER: ADC trigger 4 on timer B period
Refer to ADC4TAPER description.
28 27 26 25
ADC4 ADC4 ADC4
TDRST TDPER TDC4
rw rw rw rw
12 11 10 9
ADC4 ADC4 ADC4
TFC2 TAC2 EEV10
rw rw rw rw
24 23 22
ADC4 ADC4T ADC4T ADC4T
TFPER DC2 CRST CPER
rw rw rw
8 7 6
ADC4 ADC4 ADC4 ADC4
EEV9 EEV8 EEV7 EEV6
rw rw rw
RM0440 Rev 1
High-resolution timer (HRTIM)
21 20 19 18
ADC4T ADC4 ADC4T
CC4 TFC4 CC2
rw rw rw rw
5 4 3 2
ADC4 ADC4 ADC4
MPER MC4 MC3
rw rw rw rw
(1)
(1)
(1)
17 16
ADC4T ADC4T
BPER BC4
rw rw
1 0
ADC4 ADC4
MC2 MC1
rw rw
1011/2083
