HRTIM timer x fault register (HRTIM_FLTxR) (x = A to F)
Address offset: Block A: 0x0E8
Address offset: Block B: 0x168
Address offset: Block C: 0x1E8
Address offset: Block D: 0x268
Address offset: Block E: 0x2E8
Address offset: Block F: 0x368
Reset value: 0x0000 0000
31
30
29
FLT
Res.
Res.
Res.
LCK
rwo
15
14
13
Res.
Res.
Res.
Res.
Bit 31 FLTLCK: Fault sources lock
0: FLT1EN..FLT6EN bits are read/write
1: FLT1EN..FLT6EN bits are read only
The FLTLCK bit is write-once. Once it has been set, it cannot be modified till the next system reset.
Bits 30:6 Reserved, must be kept at reset value.
Bit 5 FLT6EN: Fault 6 enable
0: Fault 6 input ignored
1: Fault 6 input is active and disables HRTIM outputs
Bit 4 FLT5EN: Fault 5 enable
0: Fault 5 input ignored
1: Fault 5 input is active and disables HRTIM outputs
Bit 3 FLT4EN: Fault 4 enable
0: Fault 4 input ignored
1: Fault 4 input is active and disables HRTIM outputs
Bit 2 FLT3EN: Fault 3 enable
0: Fault 3 input ignored
1: Fault 3 input is active and disables HRTIM outputs
Bit 1 FLT2EN: Fault 2 enable
0: Fault 2 input ignored
1: Fault 2 input is active and disables HRTIM outputs
Bit 0 FLT1EN: Fault 1 enable
0: Fault 1 input ignored
1: Fault 1 input is active and disables HRTIM outputs
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
24
23
22
Res.
Res.
Res.
8
7
6
FLT6
Res.
Res.
Res.
RM0440 Rev 1
High-resolution timer (HRTIM)
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
FLT5
FLT4
FLT3
EN
EN
EN
EN
rw
rw
rw
rw
17
16
Res.
Res.
1
0
FLT2
FLT1
EN
EN
rw
rw
983/2083
