RM0440
29.8.8
TIMx capture/compare enable register (TIMx_CCER)(x = 16 to 17)
Address offset: 0x20
Reset value: 0x0000
15
14
13
Res.
Res.
Res.
Res.
Bits 15:4 Reserved, must be kept at reset value.
Bit 3 CC1NP: Capture/Compare 1 complementary output polarity
CC1 channel configured as output:
CC1 channel configured as input:
Note: 1. This bit is not writable as soon as LOCK level 2 or 3 has been programmed (LOCK
12
11
10
9
Res.
Res.
Res.
0: tim_oc1n active high
1: tim_oc1n active low
This bit is used in conjunction with CC1P to define the polarity of tim_ti1fp1. Refer to the
description of CC1P.
bits in TIMx_BDTR register) and CC1S="00" (the channel is configured in output).
2. On channels that have a complementary output, this bit is preloaded. If the CCPC bit
is set in the TIMx_CR2 register then the CC1NP active bit takes the new value from the
preloaded bit only when a commutation event is generated.
General-purpose timers (TIM15/TIM16/TIM17)
8
7
6
Res.
Res.
Res.
RM0440 Rev 1
5
4
3
2
Res.
Res.
CC1NP CC1NE
rw
rw
1
0
CC1P
CC1E
rw
rw
1383/2083
1399
