Table 211. Compare 1..3 Values In Interleaved Mode - ST STM32G4 Series Reference Manual

RM0440
Mode
CMP1 value
CMP2 value
CMP3 value
Note: In half and interleaved modes, the compare registers are controlled by hardware and writing
them has no effect. However the written value is stored in the preload register and becomes
active on the update event following the exit of these modes.
Note: The triple and quad interleaved modes must not be used simultaneously with other modes
using CMP2 (dual channel dac trigger and triggered-half modes).
Null duty cycle exception case
The high-resolution behavior is not supported for pulses narrower than 3 t
(see Section 26.3.7: Set / reset events priorities and narrow pulses
value strictly below 3 periods of the f
CKPSC[2:0] = 1, 0x18 if CKPSC[2:0] = 2,...) in the HRTIM_TIMxCMPy register is forbidden
(see 26.5.19: HRTIM timer x compare 1 register (HRTIM_CMP1xR) (x = A to
However, it is possible to skip an output pulse and have a null duty cycle by simply writing a
null value in the following two registers: HRTIM_TIMxCMP1 and HRTIM_TIMxCMP3, if and
only if the following conditions are met:
–
–
–
For any other use case, this can be done by programming the SET and RESET events with
the very same compare values, above 3 periods of the f
is reset forced (following the set/reset priority scheme defined in the
reset events priorities and narrow pulses
Swap mode
This mode allows to swap the two outputs with a single bit access: the output 1 signal is
connected to the output 2 pin and the output 2 signal is connected to output 1 pin. The
output swap is triggered with the SWPx bits in the HRTIM_CR2 register and is effective on
the next update event.
The outputs are swapped prior to the set/reset crossbar unit, as following:
–
–
The swap mode is only affecting the preload register, and not the active registers.
Note: The preload mode must be enabled when using the swap mode.

Table 211. Compare 1..3 values in interleaved mode

Dual interleaved
180°
PERxR/2
Not affected
Not affected
the output SET event is generated by the PERIOD event
the output RESET if generated by the compare 1 (respectively compare 3) event
the compare 1 (compare 3) event is active within the timer unit itself, and not used
for other timing units
if SWPx = 0, HRTIM_SETx1R and HRTIM_RSTx1R are coding for the output 1,
HRTIM_SETx2R and HRTIM_RSTx2R are coding for the output 2
if SWPx = 1, HRTIM_SETx1R and HRTIM_RSTx1R are coding for the output 2,
HRTIM_SETx2R and HRTIM_RSTx2R are coding for the output 1
Triple interleaved
120°
PERxR/3
2x (PERxR/3)
Not affected
clock (that is 0x60 if CKPSC[2:0] = 0, 0x30 if
HRTIM
management).
RM0440 Rev 1
High-resolution timer (HRTIM)
Quad interleaved
PERxR/4
PERxR/2
3x (PERxR/4)
HRTIM
management) and any
clock. In this case, the output
HRTIM
Section 26.3.7: Set /
90°
periods
F)).
821/2083
