RM0440
Bits 27:24 TI4SEL[3:0]: Selects tim_ti4[0..15] input
Bits 23:20 Reserved, must be kept at reset value.
Bits 19:16 TI3SEL[3:0]: Selects tim_ti3[0..15] input
Bits 15:12 Reserved, must be kept at reset value.
Bits 11:8 TI2SEL[3:0]: Selects tim_ti2[0..15] input
Bits 7:4 Reserved, must be kept at reset value.
Bits 3:0 TI1SEL[3:0]: Selects tim_ti1[0..15] input
28.5.27
TIMx alternate function register 1 (TIMx_AF1)(x = 2 to 5)
Address offset: 0x060
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
ETRSEL[1:0]
Res.
Res.
rw
rw
0000: tim_ti4_in0: TIMx_CH4
0001: tim_ti4_in1
...
1111: tim_ti4_in15
Refer to
Section 28.4.2: TIM2/TIM3/TIM4/TIM5 pins and internal signals
implementation.
0000: tim_ti3_in0: TIMx_CH3
0001: tim_ti3_in1
...
1111: tim_ti3_in15
Refer to
Section 28.4.2: TIM2/TIM3/TIM4/TIM5 pins and internal signals
implementation.
0000: tim_ti2_in0: TIMx_CH2
0001: tim_ti2_in1
...
1111: tim_ti2_in15
Refer to
Section 28.4.2: TIM2/TIM3/TIM4/TIM5 pins and internal signals
implementation.
0000: tim_ti1_in0: TIMx_CH1
0001: tim_ti1_in1
...
1111: tim_ti1_in15
Refer to
Section 28.4.2: TIM2/TIM3/TIM4/TIM5 pins and internal signals
implementation.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
General-purpose timers (TIM2/TIM3/TIM4/TIM5)
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
RM0440 Rev 1
for product specific
for product specific
for product specific
for product specific
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
Res.
Res.
Res.
Res.
17
16
ETRSEL[3:2]
rw
rw
1
0
Res.
Res.
1291/2083
1297
