Maintenance Commands
The MCU video state for this endpoint. a, b, B, c, i, r, R, s, S, u, U, v,
Vs
blank.
Quad-screen conferences = * appears before V values indicating
that an endpoint belongs to the mixed image. A # appears before the
V values indicating that an endpoint belongs to the mixed image (by
administration or UCC/CRCS Agent). Instead, a Fill video displays
in its place. This occurs when an endpoint's video that is set in a
quadrant cannot be used as a video source because the endpoint is
not connected to the conference, suppresses its video, or has invalid
video for its video source. Up to four endpoints have an * or # before
the Vs field value.
Quad-screen conference in VAS mode = The mixed image
broadcasts to all endpoints. For quad-screen conference in
presentation mode, the mixed image is return video to the presenter.
a = This value applies to quad-screen conferences. *a indicates that
an endpoint belongs to the current mixed image and is administered
to one of the quadrants. *a indicates that the endpoint is fixed in a
quadrant, but is not currently connected (Fill image displays).
b = For full-screen conferences, this endpoint's video broadcasts to
other sites. This conference is in VAS, broadcast, or presentation
mode. For quad-screen VAS conference are prefixed an asterisk
indicating that this endpoint's video is part of the mixed image
because of VAS. For quad-screen presentation conferences, b
identifies the presenter as the broadcaster.
B = The UCC roll call feature causes the endpoint's video to
broadcast to other sites. The UCC roll call feature performs in
full-screen mode.
c = This endpoint's video broadcasts to other sites. The conference
was in chair mode and the chair designates the broadcaster. Chair
features perform in full-screen mode.
