status bri-port
Point-to-point signaling link layer 2 state.
Layer2
State
un-assigned = the link is in TEI-UNASSIGN state at Layer 2.
assigned = the link is in the AWAIT_EST (Await Establish) state at layer 2.
(If BRI endpoints support TEI allocation procedures, they successfully
execute and a TEI is assigned to the endpoint by the switch.
established = the link is in the MF_EST_NORM (Multi-Frame Established
Normal) state at layer 2. The switch successfully initiates the link can now
exchange layer 3 frames with the endpoint. If the endpoint does not support
SPID initialization procedures, the endpoint extension associated with the
link also displays. This is the normal state for the link in the point-to-point
wiring configuration.
l3-established = link is in the MF_EST_NORM state at layer 2 and SPID
initialization procedures successfully complete. The endpoint extension
associated with the link also displays. This is the normal state for the link in
the multi-point wiring configuration.
hyperactive = traffic on this link goes over threshold. The link suspends and
is deemed hyperactive.
Voice/data endpoint extension associated with the link if the link is in the
Endpt
Extension
"established" (point-to-point configuration) or "l3-established" (multipoint
configuration) layer 2 state. Otherwise, this field is blank.
Identifies the SPID administered on the voice/data endpoint associated with
Endpt
SPID
the link. Appears when the link is in the "established" (point-to-point
configuration) or the "13-established" (multipoint configuration) layer 2
state. Otherwise this field is blank.
If y, the link is associated with the Service SPID, and the endpoint
Service
SPID
extension field is blank. Service SPID checks building wiring between the
switch and the BRI endpoint.
