Maintenance Commands
Does it have the required audio capability? - y, c, e, blank
Aud
y = The endpoint has the required audio capability. Audio add-on
endpoints set the Aud field y when the endpoint joins the conference.
c = This PCM-only endpoint changes conference video quality by
changing the operating audio from G.728 to G.711. If the
administered audio mode is auto and the administered bandwidth is
112 kbps (56 k/channel) or 128 kbps (64 k/channel), the system
begins with the highest common audio, G.728. When the
administered bandwidth is greater than 128 kbps, the system begins
with the highest common bandwidth, 7 kHz.
e = A PCM-only endpoint that could not support the administered
audio mode, G.728 (such as a data conference), or G. 278/G.711
endpoint that could not support the administered audio mode, 7 kHz.
Such endpoints operate with PCM audio and interwork with
operating audio modes.
"blank" = Blank until the first call is made from or to the endpoint.
Does it have required video capability and is it receiving video? - y,
Vid
c, e, n, blank
y = The endpoint has the required video capability and receives
video if the Chl, Aud, and Dat fields are y.
c = The endpoint downgrades the conference's video quality from
CIF to ACIF, or by decreasing the frame rate. The conference video
mode defaults to CIF, and if a QCIF-only endpoint joins the
conference, the entire conference operates in QCIF, with
downgraded video clarity. The conference frame rate is initially set to
the highest frame rate that can be reduced by any endpoint. If the
conference video mode is not administered with upgrade capability,
the video parameters for a conference downgrade. They do not
upgraded until all endpoints disconnect from the conference.
e = The endpoint does not declare video capability in its cap-set.
n = Audio only, not receiving video, due to an audio or data problem.
"blank" = Audio add-on endpoints set the Vid field to blank.
The relationship between the Control Link and the ESM (T.120 stack
Mlp
terminator), the endpoint MLP data capability, and the state of the
data connection in the T.120 stack. This field defaults to blank,
indicating that the Data Mode for the conference is none.
y This endpoint has Still Frame Graphics capability.
Gx
e = This endpoint did not have Still Frame Graphics capability. The
conference retains still frame graphics capability when a
non-compliant endpoint joins the conference.
"blank" = This endpoint never joins the conference.
