Maintenance Commands
Output
The following example shows the output for status access-endpoint 22502. The
command assumes that access endpoint ports for extension 22502 are in cabinet
1, carrier C, slot 11, circuit 1 to 6 — that access endpoints are connected on an
active call to ports 7 to 12 of the board in location 1B19 (cabinet 1, carrier B, slot
19). This means that port 01C1101 connects to 01B1907, port 01C1102 connects
to 01B1908, and port 01C1103 connects to 01B1909.
status access-endpoint 22502
ACCESS-ENDPOINT STATUS
Extension: 22502
(Starting) Port: 01C1101
Communication Type: wideband
Service State: in-service/active
Connected Ports: 01B1907 01B1908 01B1909
Field descriptions
Extension of the access endpoint
Extension
Port locations of the access endpoint. For wideband access endpoint,
(Starting)
Port
the location shown is that of the starting port.
The valid voice and data communication type that the access
Communication
Type
endpoint is administered. The options are: 56k-data, 64k-data,
voice-grade-data, and wideband.
For 56k-data, 64k-data, and voice-grade data, the width value is 1.
Width
For wideband, this field displays the number of DS0s that make up
the access endpoint.
in-service/active, in-service/idle, and
Service State
out-of-service
Port location connected to the access endpoint for an active call. For
Connected
Ports
wideband, all ports connected to the wideband access endpoint are
listed.
416
Issue 5 October 2002
Width: 6
01B1910 01B1911 01B1912
