Avaya DEFINITY Server CSI Maintenance Manual page 464

Maintenance Commands
The High Speed MLP mode. The HMLP mode should be
H_MLP
H-MLP-off. Other values in this mode will affect video status.
Low Speed Data mode. The LSD mode should be LSD-off. Other
LSD
values in this mode affect video status.
High Speed Data mode. The HSD mode should be HSD-off. Other
HSD
values in this mode affect video status.
Encryption mode. The CRYPT mode should be encrypt-off.
CRYPT
Other values in this mode affect video status.
Single/Multi channel interoperability mode. 6B-H0-comp indicates
S/M
that the sender is interoperating multiple channels and a single
channel (for example, 6B and H0). Not-comp-6B-H0 indicates that
the sender is not interoperating between 6B and H0. Normally this
value is Not-comp-6B-H0. Other values in this mode affect video
status.
Endpoint Miscellaneous (EPT MISC) Information. EPT MISC contains
miscellaneous states and counters for an endpoint. Flags can y or n. Counters
start with 0x00, increment to 0xff, and wrap around to 0x01. AIM and VIS are BAS
commands that can be sent as input to MCU from an endpoint or as output from
MCU to an endpoint
Field descriptions
Audio Indicate Mutes.
AIM
y = For input, this endpoint mutes its audio. MCU does not VAS to an endpoint
displaying mute. For output, all other endpoints in the conference mute their
audio (have sent AIM to MCU). MCU in turn tells this endpoint (by sending it
AIM) that there is no audio output from MCU.
n = For input, this endpoint does not mute (only if endpoint audio mode is
turned on). For output, an audio path opens across the bridge.
Video Indicate Suppressed.
VIS
y = For input, this endpoint suppresses its video (video is muted). For output,
the MCU is not sending video to this endpoint because there is no video
broadcaster (broadcaster does not join or broadcaster's video is invalid).
Multipoint Indicate Secondary-status.
MIS
n = For output, the endpoint is a valid source (not necessarily at this moment).
n is the correct state for the video.
y = MIS was sent to an endpoint considered to be a secondary endpoint. The
endpoint is included in the audio, but not video portion of the conference. Video
is not sent.
