status conference
MCU endpoint video state (a, b, B, c, i, r, R, s, S, u, U, v, blank).
Vs
Quad-screen conferences = an * appears before the Vs value
indicating that an endpoint belongs to the mixed image. # appears
before Vs values indicating that an endpoint is set to be in the mixed
image (via administration or UCC/CRCS Agent), but instead, Fill
video displays in its place. This occurs when videos of an endpoint that
are set in a quadrant cannot be used as a video sources, because the
endpoint is not joined to the conference, suppresses its video, or has
invalid video for its video source. Up to four endpoints may have an *
or # before the Vs field value.
Quad-screen conferences in VAS mode = Mixed images broadcast to
all endpoints.
Quad-screen conferences in presentation mode = Mixed images are
return videos to the presenter.
Vs
a = Applies to quad-screen conferences. *a indicates that an endpoint
(cont'd.)
belongs to the mixed image and is administered to one of the
quadrants, but is not currently connected (Fill image displays).
b = Applies to full-screen conferences. This endpoint's video
broadcasts to other sites. This conference is in VAS, broadcast, or
presentation mode. Quad-screen VAS conferences are prefix with an *
indicating that this endpoint's video belongs to the mixed image.
Quad-screen presentation conferences, (b without an asterisk) identify
the presenter as the broadcaster.
B = The UCC roll call feature causes the endpoint's video to broadcast
to other sites. The UCC roll call feature performs in full-screen mode.
c = This endpoint's video broadcasts to other sites. The conference is
in chair mode and the chair designates the broadcaster. Chair features
perform in full-screen mode.
i = The endpoint is not a valid video source. #i represents continuous
presence conferences with endpoints that are set in particular
quadrants.
r = For full-screen conferences, the endpoint's video is the return video
to the broadcaster. For continuous presence conference in
presentation mode, *r represents a VAS quadrant that belongs to the
mixed image.
R = The UCC browse feature causes the endpoint's video to return
video to the broadcaster. UCC Browse feature perform in full-screen
mode.
s = The endpoint suppresses this endpoint's video. For continuous
presence conference with fixed quadrant participants, #s represents
endpoints that are fixed in a particular quadrant.
