Avaya DEFINITY Server CSI Maintenance Manual page 466

Maintenance Commands
Frame Alignment Word (FAW) Information. The FAW section of page 3
provides channel Frame Alignment Word information for the communication paths
labeled CHL 1 and 2. For 2B calls, both CHL 1 and 2 are used. For 1-channel
calls (112,bps, 128kbps, 168kbps, 196kbps, 224kbps, 256kbps, 280kbps,
320kbps, 336kbps, 384kbps, 768kbps, 1472kbps, 1536kbps, and 1920kbps) only
CHL 1 is used. A-OUT, A-IN, M-FRM, MFA, and MFN are flags with y or n.
Field descriptions
MCU has endpoint framing.
A-OUT
Endpoint has MCU framing
A-IN
Multichannel frame alignment of both channels in 2B is present.
M-FRM
Multiframe alignment word is present (required in 2B call).
MFA
Multiframe numbering is present (required in 2B call).
MFN
Frame Alignment Signal (FAS) channel number (1 or 2). This number should
FAS
match the column header.
MCU Frame Alignment Loss (MCUFAL). Counts the number of times the
MCUFAL
MCU reports lost endpoint FAW or multichannel synchronization (M-FRM) to
the endpoint. The MCU a-bit toggles when the MCU gains or loses endpoint
multichannel synchronization. This counter starts with 0x00, increments to
0xff, then wraps around to 0x01. The MCUFAL count also displays in the Fr
Err field on Page 2
Far End Frame Alignment Loss (FEFAL). Counts of the number of changes
FEFAL
the MCU detects in the endpoint's a-bit (A-OUT). The endpoint a-bit toggles
when an endpoint gains or loses MCU framing. This counter starts with 0x00,
increments to 0xff, then wraps around to 0x01.
466
Issue 5 October 2002
555-233-119
