Avaya DEFINITY Server CSI Maintenance Manual page 428

Maintenance Commands
Output
For the following example shows the output from status bri-port 1c1701.
status bri-port 1c1701
Port: 01C1701
Service State: in-service
Maintenance Busy?: no
Layer 1 State: activated
TEI Value
Link1 64
Link2
Link3
Field descriptions
ISDN-BRI port address.
Port
ISDN-BRI port is "in-service" or "out-of-service."
Service
State
specifies if maintenance testing is executing on the ISDN-BRI port (y/n)
Maintenan
ce Busy?
BRI Layer 1 (physical) state on the port.
Layer 1
State
activated = layer 1 frames are passing between the port and BRI
endpoints.
pend-activation = the port is in-service, the layer 1 interface device is
on, layer 1 frames are sending to the BRI endpoints connected to this
port, but BRI endpoints are not responding.
deactivated = the layer 1 interface device on the BRI is off, because the
port goes out-of-service.
Identifies the addressing parameter value (0–127).
TEI Value
Layer 2 addressing parameter used by the switch to exchange information
over point-to-point signaling links between BRI endpoints. Each
point-to-point signaling link has an associated TEI.
428
Issue 5 October 2002
STATUS BRI-PORT
Layer2 State Endpt Extension
13-established 1010
Page 1 of 1 SPE A
Endpt SPID
1010
Service SPID?
555-233-119
