2 In the New Family – Select Template File dialog, select Entourage.rft or Metric Entourage.rft,
3 In the drawing area, sketch the geometry to represent the entourage in 2D and 3D views, or
4 Specify visibility settings for the entourage placeholder, as follows:
5 Create family types, and specify their parameters.
6 Specify a render appearance.
7 Save the family.
8 Load the family into a project.

Using the ArchVision Content Manager

Revit Architecture provides many RPC objects that you are licensed to use in rendered images for Revit
projects. If you purchase additional RPC content, you must use the ArchVision Content Manager (ACM) to
manage it.
NOTE Use the ACM only to manage additional RPC content that you purchase from ArchVision. You do not need
to use the ACM for the RPC content that is provided with Revit Architecture.
If the additional RPC content resides on the local computer, you must configure Revit Architecture to access
it. See Configuring Revit Architecture for Local RPC Content
If your organization stores additional RPC content in a network location, you need to specify network paths
for the RPC files and for the ACM. See
1150.
and click Open.
import a CAD file that contains the geometry.
See Family Editor on page 376 or
a In the drawing area, select the placeholder.
b On the Options Bar, click Visibility.
c In the Family Element Visibility Settings dialog, select the desired settings.
See Visibility and Detail Levels
d Click OK.
See Family Types on page 366.
By default, for an entourage family, Revit Architecture uses the family geometry (that you
imported or sketched in the drawing area) to represent the object in a rendered image. If you
want to specify an RPC file to define its geometry, do the following:
a Click Settings Family Category and Parameters.
b Under Family Parameters, for Rendering Appearance Source, select Third Party.
NOTE If you want to use the geometry that you create or import for a render appearance, for
Rendering Appearance Source, select Family Geometry.
c Click OK.
d Specify the render appearance.
See Specifying a Render Appearance for an RPC Family
Importing or Linking CAD Formats
on page 360.
on page 1150.
Configuring Revit Architecture for Networked RPC Content
Using the ArchVision Content Manager | 1149
on page 1307.
on page 1144.
on page
