Controlling the Brightness of a Light Source

In a project, you can change the brightness of a light source using the following methods:
Change the Initial Intensity. For example, if you want to change the bulb in a table lamp from a 60 watt
bulb to a 100 watt bulb, change its Initial Intensity value in the type properties.
Change the Light Loss Factor. To enhance or reduce light output to reflect environmental factors in the
project, change this value in the type properties for the lighting fixture.
Dim the light. Use this method, for example, if you want to represent a ceiling light that is dimmed to
create mood lighting in a rendered image.
Changing the Initial Intensity of a Light Source
When you change the initial intensity of a light source, the change affects all relevant project views.
1 In a project view, select a lighting fixture, and click
2 In the Element Properties dialog, click Edit/New.
3 Click Duplicate to create a new type.
4 Enter a name for the type, and click OK.
5 In the Type Properties dialog, for Initial Intensity, click in the Value column.
6 In the Initial Intensity dialog, specify the desired value.
See Initial Intensity Parameters
7 Click OK 3 times.
Changing the Light Loss Factor for a Light Source
When you change the Light Loss Factor for a light source, the change affects all relevant project views.
on page 1125.
Using Lighting Fixtures in a Building Model | 1133
(Element Properties).
